Horsepower & Torque: OEM
Cylinder Heads: Cast Iron Vortec
Compression Ratio: OEM
Camshaft: Hydraulic Roller Cam - .414 Intake / .428 Exhaust Lift and 191 Intake / 194 Exhaust Duration @ .050-111° LSA
Pistons: Hypereutectic
Crankshaft: Cast Crank - 3.480" Stroke and 5.700" Rods
Fuel Recommendation: 87+ Octane
- Description
- Engine Specs
- Parts & Accessories
- Warranty
Description:
This engine is designed and manufactured to factory specs for the specified vehicles below. It's manufactured using tighter machining tolerances, higher quality components, and finer balancing of the rotating assembly to make this engine better than the original while still meeting the description of a “replacement” engine.
Block:
- BluePrint Engines Hight Strength Cast Iron Block
- 4-Bolt Main
- 4.000" Bore
- 1-Piece Rear Main Seal
- Mech Fuel Pump Provision: NO! -OE Vortec Cam does not Feature a Pump Lobe
- Passenger Side Dipstick
- Drilled and Tapped for Clutch Linkage
Rotating Assembly:
- Cast Crankshaft
- 3.480" Stroke
- Forged 5.700" Connecting Rods
- Hypereutectic Pistons
- Internally Balanced Front - Externally Balanced Rear
Cylinder Heads:
- Vortec Iron Heads
Cam Specs:
- Hydraulic Roller
- OEM Spec Per Listed Vehicles
Ignition Timing:
- OEM Specifications
Also Includes:
- Valve Covers
- Rear Sump Oil Pan
- Timing Cover
- Harmonic Balancer
Notes:
- Designed as factory replacement long block for specified vehicles and year ranges, using OEM specification parts. Customer to re-use existing intake manifold, ecu (if equipped), exhaust, fuel system etc. Modification or replacement of provided tinware, and minor accommodations such as dipstick location may be required.
- Specifically designed as an OEM spec engine to meet emissions requirements of the specified vehicles, to meet the criteria of "replacement engine" in all 50 states.
- Note this engines camshaft does not feature a mechanical fuel pump lobe.
- Must verify with application list linked above for fitment.
Blocks
- BluePrint Engines Hight Strength Cast Iron Block
- 4-Bolt Main
- 4.000" Bore
- 1-Piece Rear Main Seal
- Mech Fuel Pump Provision: NO! -OE Vortec Cam does not Feature a Pump Lobe
- Passenger Side Dipstick
- Drilled and Tapped for Clutch Linkage
Cylinder Heads
Cast Iron Vortec
Ignition Timing
Controlled by OEM ECU
Spark Plug
.060 in.
Firing Order
1,8,4,3,6,5,7,2
Rotating Assembly
- Cast Crankshaft
- 3.480" Stroke
- Forged 5.700" Connecting Rods
- Hypereutectic Pistons
- Internally Balanced Front - Externally Balanced Rear
Cam Specs
- Hydraulic Roller
- OEM Spec Per Listed Vehicles
Stall Converter
OEM
Also Includes
- Valve Covers
- Rear Sump Oil Pan
- Timing Cover
- Harmonic Balancer
Notes
- Designed as factory replacement long block for specified vehicles and year ranges, using OEM specification parts. Customer to re-use existing intake manifold, ecu (if equipped), exhaust, fuel system etc. Modification or replacement of provided tinware, and minor accommodations such as dipstick location may be required.
- Specifically designed as an OEM spec engine to meet emissions requirements of the specified vehicles, to meet the criteria of "replacement engine" in all 50 states.
- Note this engines camshaft does not feature a mechanical fuel pump lobe.
- Must verify with application list linked above for fitment.
Your BluePrint engine was dyno tested with the parts and specifications listed below. If you prefer to install a different part, your engine may not produce the horsepower recorded on your dyno sheet.
Parts & Accessories Specs
| Intake Manifold (Not Included) | N/A - Reuse OEM |
|---|---|
| Spark Plug (Not Included) | ACDELCO-R44LTS6 |
| Harmonic Balancer | BPP350 |
| Flexplate/Flywheel (Not Included) | BPP871006 |
| Fuel Recommendation | 87+ Octane |
| Recommended Service Oil | BPP10W30 |
| Recommended Oil Filter | BPP51061 |
| Total Oil Capacity with Production Oil Pan, and Correct Filter | 5 Quarts |
Header Partners:
- Click Here for our Header Partners and recommendations.
Better Than the Rest.
The satisfaction of our customers is our highest priority at BluePrint Engines. We use quality components to balance your engine's rotating assembly within two grams of spec. We dyno test your crate engine and certify that it's ready to deliver horsepower and torque.
We give your BluePrint engine the industry's best-in-class warranty for 30-months / 50,000 miles — with the extra confidence only BluePrint can provide. Our warranty applies to individual or professional installations and is fully transferable. View detailed overview
Already Own this engine?
Protect your investment by registering your warranty today. Register below to ensure coverage and stay up to date on important service information.
Register NowEVERY BLUEPRINT ENGINE ACES THE DYNO TEST
We make sure we hit our target horsepower and proper torque with every crate engine. We use an advanced computerized balancer in our in-house dyno testing rooms to get our rotating assemblies within two grams, ensuring silky smooth power over the entire RPM range. That’s precisely why our engines sound and run better than our competitors.
All specs, zero speculation: A comprehensive, dyno-generated printout showing your critical engine specs will accompany your delivered engine — every time. No more guessing or wondering what your installed engine’s real-world peak horsepower and torque ratings actually are. Any doubters in the crowd? Simply flash ‘em your exact engine’s dyno results.
